| 芯数 | 标称导体截面积 | 股数/ 直径 | 标称绝缘厚度 | 标称内衬厚度 | 标称铝丝铠装直径 | 标称护套厚度 | 标称外径 | 标称电缆重量 |
|---|---|---|---|---|---|---|---|---|
| MM² | NO./MM | MM | MM | MM | MM | MM | KG/MM | |
| 7 | 1.5 | 7/0.53 | 0.6 | 0.8 | 0.9 | 1.4 | 15.2 | 500 |
| 10 | 1.5 | 7/0.53 | 0.6 | 0.8 | 1.25 | 1.5 | 18.6 | 780 |
| 12 | 1.5 | 7/0.53 | 0.6 | 0.8 | 1.25 | 1.5 | 19.4 | 830 |
| 19 | 1.5 | 7/0.53 | 0.6 | 0.8 | 1.25 | 1.6 | 22.2 | 1090 |
| 27 | 1.5 | 7/0.53 | 0.6 | 1.0 | 1.6 | 1.7 | 26.7 | 1600 |
| 37 | 1.5 | 7/0.53 | 0.6 | 1.0 | 1.6 | 1.8 | 29.2 | 1940 |
| 48 | 1.5 | 7/0.53 | 0.6 | 1.0 | 1.6 | 1.9 | 32.9 | 2360 |
| 7 | 2.5 | 7/0.67 | 0.7 | 0.8 | 1.25 | 1.5 | 18.0 | 750 |
| 10 | 2.5 | 7/0.67 | 0.7 | 0.8 | 1.25 | 1.6 | 21.8 | 1000 |
| 12 | 2.5 | 7/0.67 | 0.7 | 0.8 | 1.25 | 1.6 | 22.4 | 1080 |
| 19 | 2.5 | 7/0.67 | 0.7 | 1.0 | 1.6 | 1.7 | 26.6 | 1640 |
| 27 | 2.5 | 7/0.67 | 0.7 | 1.0 | 1.6 | 1.8 | 30.7 | 2110 |
| 37 | 2.5 | 7/0.67 | 0.7 | 1.0 | 1.6 | 1.9 | 34.0 | 2600 |
| 48 | 2.5 | 7/0.67 | 0.7 | 1.2 | 2.0 | 2.1 | 39.5 | 3520 |
| 7 | 4 | 7/0.85 | 0.8 | 0.8 | 1.25 | 1.6 | 20.5 | 970 |
| 10 | 4 | 7/0.85 | 0.8 | 1.0 | 1.6 | 1.7 | 26.1 | 1500 |
| 12 | 4 | 7/0.85 | 0.8 | 1.0 | 1.6 | 1.7 | 26.8 | 1630 |
| 19 | 4 | 7/0.85 | 0.8 | 1.0 | 1.6 | 1.8 | 30.5 | 2170 |
| 27 | 4 | 7/0.85 | 0.8 | 1.2 | 2.0 | 2.0 | 37.1 | 3170 |
| 37 | 4 | 7/0.85 | 0.8 | 1.2 | 2.0 | 2.1 | 40.8 | 3910 |
| 48 | 4 | 7/0.85 | 0.8 | 1.2 | 2.0 | 2.2 | 46.0 | 4790 |
